3HXOL Series L-Shaped Fluoropolymer (PTFE) Heaters
3HXOL Series L-Shaped Fluoropolymer (PTFE) Heaters
SKU:HEA-69e8a6
Efficient and durable 3HXOL Series L-Shaped Fluoropolymer (PTFE) Heaters with diverse protection options for industrial heat transfer applications.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
3HXOL Series L-Shaped Fluoropolymer (PTFE) Heaters
$899.99
Quantity: 1
Claim Your Seller Account
3HXOL Series L-Shaped Fluoropolymer (PTFE) Heaters
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3HXOL Series Multi Element L-Shaped Fluoropolymer (PTFE) Heaters are precision-engineered for optimal performance in industrial heating applications. Featuring a robust construction with a 10 W/in² watt density, 18,000 W power output, and various thermal overload protection options, these heaters ensure efficient heat transfer and long-lasting durability. Designed to meet diverse needs, the 3HXOL heaters come with standard polypropylene guards and optional PTFE guards for enhanced chemical resistance. Certified by CE and UL, these heaters from Process Technology adhere to the highest quality and safety standards, making them ideal for a wide range of industrial processes.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Certifications
CE | UL Listed
Specifications Element Type
Multi Element
Specifications Guards Recommended
Standard guard is polypropylene. Fluoropolymer (PTFE) guards recommended for chromic acid and solutions exceeding 180º F (82ºC).
Specifications Guard Model Number
3HXOL10.5-42-R*-G
Specifications Hot Zone
42 " | 1067 mm
Specifications Manufacturer
Process Technology
Specifications Material
Fluoropolymer (PTFE)
Specifications Max Cold Zone
25 " | 635 mm
Specifications Options Available
Comes Standard with Replaceable thermal protector: P1: for solutions up to 180°F (82°C). | Resettable thermal protector: P2: for solutions up to 180°F (82°C). | Resettable thermal protector: P3: for solutions up to 250°F (121°C). | Resettable thermal protector: P8: for solutions up to 210°F (99°C).
Specifications Phase
Single | Three (Standard)
Specifications Series
3HXOL Series
Specifications Shipping Weight
54.0 Pound
Specifications Standard Vertical Length
18 " | 457 mm
Specifications Volts
240 V
Specifications Watts
18,000 W
Specifications Watt Density
10 W/in² | 1.5 W/cm²
Specifications Weight
54.0 lbs | 24.5 kg
Specifications Width
10-1/2 " | 263 mm
