3HXOL Series L-Shaped PTFE Heaters
3HXOL Series L-Shaped PTFE Heaters
SKU:HEA-ef3f5e
High-performance 9000W PTFE Heaters with customizable thermal protection options for industrial applications.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
3HXOL Series L-Shaped PTFE Heaters
$799.99
Quantity: 1
Claim Your Seller Account
3HXOL Series L-Shaped PTFE Heaters
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3HXOL Series Multi Element L-Shaped Fluoropolymer (PTFE) Heaters are versatile and efficient heating solutions designed for a range of industrial applications. With a power output of 9000W and a watt density of 10 W/in², these heaters provide reliable performance. The PTFE material construction ensures excellent chemical resistance, making them ideal for corrosive environments. Each unit comes with various thermal overload protection options, allowing customization based on specific temperature requirements. Manufactured by Process Technology, these heaters meet CE and UL Listed certifications, guaranteeing quality and safety.
Product Specifications
Specifications Certifications
CE | UL Listed
Specifications Element Type
Multi Element
Specifications Guards Recommended
Standard guard is polypropylene. Fluoropolymer (PTFE) guards recommended for chromic acid and solutions exceeding 180º F (82ºC).
Specifications Guard Model Number
3HXOL10.5-23-R*-G
Specifications Hot Zone
23 " | 584 mm
Specifications Manufacturer
Process Technology
Specifications Material
Fluoropolymer (PTFE)
Specifications Max Cold Zone
35 " | 889 mm
Specifications Options Available
Comes Standard with Replaceable thermal protector: P1: for solutions up to 180°F (82°C). | Resettable thermal protector: P2: for solutions up to 180°F (82°C). | Resettable thermal protector: P3: for solutions up to 250°F (121°C). | Resettable thermal protector: P8: for solutions up to 210°F (99°C).
Specifications Phase
Single | Three (Standard)
Specifications Series
3HXOL Series
Specifications Shipping Weight
36.0 Pound
Specifications Standard Vertical Length
18 " | 457 mm
Specifications Volts
480 V
Specifications Watts
9000 W
Specifications Watt Density
10 W/in² | 1.5 W/cm²
Specifications Weight
36.0 lbs | 16.3 kg
Specifications Width
10-1/2 " | 263 mm
