3HXOL Series PTFE Multi Element L-Shaped Heaters
3HXOL Series PTFE Multi Element L-Shaped Heaters
SKU:HEA-713d37
High-performance 9000W PTFE Multi Element L-Shaped Heaters with thermal protection options. Ideal for various applications.
Regular price
$549.99
Regular price
Sale price
$549.99
Unit price
per
Initiate Order
3HXOL Series PTFE Multi Element L-Shaped Heaters
$549.99
Quantity: 1
Claim Your Seller Account
3HXOL Series PTFE Multi Element L-Shaped Heaters
$549.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3HXOL Series PTFE Multi Element L-Shaped Heaters offer superior heating performance with 9000W power, 10 W/in² watt density, and durable Fluoropolymer (PTFE) construction. Designed for efficiency, these heaters come with thermal overload protection options, ensuring safe operation. With a CE and UL Listed certification, these heaters meet stringent quality standards and are ideal for a wide range of applications, including those requiring resistance to chromic acid and high temperatures. Guards recommended for specific solutions are available separately.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Certifications
CE | UL Listed
Specifications Element Type
Multi Element
Specifications Guards Recommended
Standard guard is polypropylene. Fluoropolymer (PTFE) guards recommended for chromic acid and solutions exceeding 180º F (82ºC).
Specifications Guard Model Number
3HXOL10.5-23-R*-G
Specifications Hot Zone
23 " | 584 mm
Specifications Manufacturer
Process Technology
Specifications Material
Fluoropolymer (PTFE)
Specifications Max Cold Zone
35 " | 889 mm
Specifications Options Available
Comes Standard with Replaceable thermal protector: P1: for solutions up to 180°F (82°C). | Resettable thermal protector: P2: for solutions up to 180°F (82°C). | Resettable thermal protector: P3: for solutions up to 250°F (121°C). | Resettable thermal protector: P8: for solutions up to 210°F (99°C).
Specifications Phase
Single | Three (Standard)
Specifications Series
3HXOL Series
Specifications Shipping Weight
36.0 Pound
Specifications Standard Vertical Length
18 " | 457 mm
Specifications Volts
240 V
Specifications Watts
9000 W
Specifications Watt Density
10 W/in² | 1.5 W/cm²
Specifications Weight
36.0 lbs | 16.3 kg
Specifications Width
10-1/2 " | 263 mm
