4.0mm Open End Countersunk Blind Rivet
4.0mm Open End Countersunk Blind Rivet
SKU:OPE-9e0f7f
High-quality 4.0mm Open End Countersunk Blind Rivet for reliable and sturdy fastening. Aluminum Alloy body with Zinc Plated Chromium Mandrel.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
4.0mm Open End Countersunk Blind Rivet
$29.99
Quantity: 1
Claim Your Seller Account
4.0mm Open End Countersunk Blind Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.0mm Diameter and 10.0mm Body Length Open End Countersunk Blind Rivet is a high-quality fastening solution suitable for various applications. Manufactured with Aluminum Alloy (AA 5052) body and Zinc Plated Chromium (Cr) VI Free Low Carbon Steel SAE 1006-1022 mandrel, it offers exceptional strength and corrosion resistance. With a nominal shear force of 100 kgf and a tensile force of 160 kgf, this rivet ensures reliable and sturdy fastening. Its precise dimensions and durable finish make it a dependable choice for both consumer and institutional projects.
Product Specifications
Nominal Dimensions Body Length
10.0 mm | 0.394 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.1 mm | 0.161 in
Nominal Dimensions Head Diameter
7.2 mm | 0.283 in
Nominal Dimensions Head Thickness
1.10 mm | 0.043 in
Nominal Dimensions Mandrel Diameter
2.31 mm | 0.091 in
Nominal Dimensions Maximum Grip Range
5.5 mm | 0.217 in
Nominal Dimensions Minimum Grip Range
3.5 mm | 0.138 in
Nominal Forces Nominal Shear Force
100 kgf | 220 lbf
Nominal Forces Nominal Tensile Force
160 kgf | 352 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
7000
Technical Specs Head Style
Countersunk
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
