4.0mm U-Fix Dome Head Rivet
4.0mm U-Fix Dome Head Rivet
SKU:UFI-5bf8b8
Versatile 4.0mm Dome Head Rivet for secure and durable fastening in various applications. Aluminum body, Steel mandrel, meets industry standards.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
4.0mm U-Fix Dome Head Rivet
$49.99
Quantity: 1
Claim Your Seller Account
4.0mm U-Fix Dome Head Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.0mm U-Fix Dome Head Rivet is a high-quality fastener designed for versatility and durability. Crafted with Aluminum Alloy ALmg 2.5 body material and Stainless Steel AISI 430/434 mandrel, it offers exceptional grip strength with a minimum range of 3.2mm and a maximum range of 7.9mm. With a shear force of 116kgf and a tensile force of 170kgf, this rivet ensures secure fastening in a variety of applications. From main cabin installations to industrial uses, this rivet is a reliable choice that meets stringent industry standards.
Product Specifications
Nominal Dimensions Body Length
11.1 mm | 0.437 in
Nominal Dimensions Diameter
4.0 mm | 5/32 in
Nominal Dimensions Drillhole Size
4.1 mm | 0.161 in
Nominal Dimensions Head Diameter
7.9 mm | 0.311 in
Nominal Dimensions Head Thickness
1.20 mm | 0.047 in
Nominal Dimensions Mandrel Diameter
2.11 mm | 2.25 mm | 0.083 in | 0.089 in
Nominal Dimensions Maximum Grip Range
7.9 mm | 0.311 in
Nominal Dimensions Minimum Grip Range
3.2 mm | 0.126 in
Nominal Forces Nominal Shear Force
116 kgf | 255 lbf
Nominal Forces Nominal Tensile Force
170 kgf | 374 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
7000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Stainless Steel AISI 430/434 or Equivalent
