4.0mm x 10.0mm Closed End Blind Rivet
4.0mm x 10.0mm Closed End Blind Rivet
SKU:CLO-346da6
Reliable 4.0mm x 10.0mm Blind Rivet for strong fastening, ideal for various applications. Compliant with Federal standards.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
4.0mm x 10.0mm Closed End Blind Rivet
$39.99
Quantity: 1
Claim Your Seller Account
4.0mm x 10.0mm Closed End Blind Rivet
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.0mm Diameter and 10.0mm Body Length Closed End Blind Rivet by Ornit is a reliable fastening solution crafted from Aluminum Alloy with a Black Phosphate Finish mandrel. With a Nominal Shear Force of 153 kgf and a Nominal Tensile Force of 214 kgf, this rivet guarantees durability and strength. Its precise dimensions and grip range make it ideal for various applications, ensuring a secure and lasting bond under intense stress. Compliant with Federal procurement standards and industry certifications, this rivet is a top choice for both consumer and institutional buyers.
Product Specifications
Nominal Dimensions Body Length
10.0 mm | 0.394 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.1 mm | 0.161 in
Nominal Dimensions Head Diameter
8 mm | 0.315 in
Nominal Dimensions Head Thickness
1.70 mm | 0.067 in
Nominal Dimensions Mandrel Diameter
2.2 mm | 0.087 in
Nominal Dimensions Maximum Grip Range
5.0 mm | 0.197 in
Nominal Dimensions Minimum Grip Range
3.5 mm | 0.138 in
Nominal Forces Nominal Shear Force
153 kgf | 336.6 lbf
Nominal Forces Nominal Tensile Force
214 kgf | 470.8 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
