4.8mm U-Fix Aluminum Dome Rivet
4.8mm U-Fix Aluminum Dome Rivet
SKU:UFI-69a01b
Versatile 4.8mm Aluminum Dome Rivet for secure fastening. Ideal for various applications. High-quality Aluminum Alloy construction.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
4.8mm U-Fix Aluminum Dome Rivet
$49.99
Quantity: 1
Claim Your Seller Account
4.8mm U-Fix Aluminum Dome Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.8mm U-Fix Aluminum Dome Rivet is a versatile and durable fastener designed for various applications like securing rails, automotive components, and more. Made of high-quality Aluminum Alloy, this rivet offers a secure grip range of 4.8mm to 11.1mm, with a nominal shear force of 100 kgf and a tensile force of 150 kgf. Its dome head design ensures enhanced aesthetics and strength, meeting the stringent requirements of interior cabin and mainframe structures.
Product Specifications
Applications Automotive Application
InteriorThe U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Nominal Dimensions Body Length
15.1 mm | 0.594 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.8 mm | 0.386 in
Nominal Dimensions Head Thickness
1.45 mm | 0.057 in
Nominal Dimensions Mandrel Diameter
2.91 mm | 0.115 in
Nominal Dimensions Maximum Grip Range
11.1 mm | 0.437 in
Nominal Dimensions Minimum Grip Range
4.8 mm | 0.189 in
Nominal Forces Nominal Shear Force
100 kgf | 220 lbf
Nominal Forces Nominal Tensile Force
150 kgf | 330 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 1.0
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy ALmg 5.0
