4.8mm U-Fix Aluminum Steel X-Large Rivet
4.8mm U-Fix Aluminum Steel X-Large Rivet
SKU:UFI-bd4a00
Versatile 4.8mm U-Fix Aluminum Steel X-Large Rivet for secure fastening in automotive interiors.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
4.8mm U-Fix Aluminum Steel X-Large Rivet
$29.99
Quantity: 1
Claim Your Seller Account
4.8mm U-Fix Aluminum Steel X-Large Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.8mm U-Fix Aluminum Steel X-Large Rivet is a versatile and purpose-built fastener designed for a wide range of applications. Crafted from durable Aluminum Alloy ALmg 2.5 with a zinc-plated chromium mandrel, it offers excellent multi-grip functionality. With a maximum grip range of 19.8mm and a nominal tensile force of 240 kgf, this rivet ensures secure and reliable fastening. Ideal for interior automotive applications, it meets stringent industry standards for performance and durability.
Product Specifications
Applications Automotive Application
InteriorThe U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Nominal Dimensions Body Length
24.8 mm | 0.976 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
15.85 mm | 0.624 in
Nominal Dimensions Head Thickness
1.75 mm | 0.069 in
Nominal Dimensions Mandrel Diameter
2.8 mm | 0.110 in
Nominal Dimensions Maximum Grip Range
19.8 mm | 0.780 in
Nominal Dimensions Minimum Grip Range
12.7 mm | 0.500 in
Nominal Forces Nominal Shear Force
159 kgf | 350 lbf
Nominal Forces Nominal Tensile Force
240 kgf | 528 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
2500
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel
