4.8mm x 10.0mm Closed End Blind Rivet
4.8mm x 10.0mm Closed End Blind Rivet
SKU:CLO-8dc77f
Ornit's 4.8mm x 10.0mm rivet: Strong, durable, compliant.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
4.8mm x 10.0mm Closed End Blind Rivet
$49.99
Quantity: 1
Claim Your Seller Account
4.8mm x 10.0mm Closed End Blind Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior fastening with the 4.8mm diameter and 10.0mm body length closed end blind rivet from Ornit. Made of aluminum alloy to AA 5052 standards, with a black phosphate mandrel, this rivet offers reliable performance. With a shear force of 224 kgf and a tensile force of 316 kgf, it ensures secure connections. Ideal for industrial use, it complies with Federal/DoD procurement standards, FAR requirements, and industry-specific certifications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
10.0 mm | 0.394 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
6.0 mm | 0.236 in
Nominal Dimensions Minimum Grip Range
4.0 mm | 0.157 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
