4.8mm x 11.0mm Closed End Blind Rivet
4.8mm x 11.0mm Closed End Blind Rivet
SKU:CLO-95b57a
High-strength 4.8mm x 11.0mm rivet, perfect for secure fastening in diverse applications.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
4.8mm x 11.0mm Closed End Blind Rivet
$79.99
Quantity: 1
Claim Your Seller Account
4.8mm x 11.0mm Closed End Blind Rivet
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.8mm diameter and 11.0mm body length closed end blind rivet by Ornit is expertly crafted from aluminum alloy (AA 5052) with a black phosphate finish low carbon steel mandrel. With a shear force of 224kgf and a tensile force of 316kgf, this rivet ensures secure fastening in a range of applications. Measuring 9.5mm in head diameter and featuring a grip range from 5.0mm to 6.5mm, this rivet meets stringent standards for durability and reliability.
Product Specifications
Nominal Dimensions Body Length
11.0 mm | 0.433 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
6.5 mm | 0.256 in
Nominal Dimensions Minimum Grip Range
5.0 mm | 0.197 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
