4.8mm x 9.5mm Closed End Blind Rivet
4.8mm x 9.5mm Closed End Blind Rivet
SKU:CLO-e49cdb
High-performance 4.8mm x 9.5mm Closed End Rivet for strong and reliable fastening in aluminum alloy structures.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
4.8mm x 9.5mm Closed End Blind Rivet
$59.99
Quantity: 1
Claim Your Seller Account
4.8mm x 9.5mm Closed End Blind Rivet
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.8mm Diameter and 9.5mm Body Length Closed End Blind Rivet by Ornit is designed for secure fastening in aluminum alloy structures. With a shear force of 224 kgf and a tensile force of 316 kgf, this rivet offers reliable performance. The aluminum alloy body and low carbon steel mandrel ensure durability and strength. Meeting stringent industry standards, this rivet is ideal for a wide range of applications requiring precision and strength.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
9.5 mm | 0.374 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
5.0 mm | 0.197 in
Nominal Dimensions Minimum Grip Range
3.5 mm | 0.138 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
