4-Inch See-Through Inlet Vacuum Air Filter - 520 CFM
4-Inch See-Through Inlet Vacuum Air Filter - 520 CFM
SKU:SEE-f79f70
4-Inch See-Through Inlet Vacuum Air Filter - Ideal for extreme duty applications, offering heat resistance and durability. Compliant with Federal standards.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
4-Inch See-Through Inlet Vacuum Air Filter - 520 CFM
$149.99
Quantity: 1
Claim Your Seller Account
4-Inch See-Through Inlet Vacuum Air Filter - 520 CFM
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4-Inch See-Through Inlet Vacuum Air Filter for 520 CFM offers high heat resistance and durability, making it ideal for extreme duty applications. Constructed with a polycarbonate bucket, it ensures maintenance simplicity through visual inspections and can withstand impacts at full vacuum. With a maximum temperature rating of 290 ºF, this filter features a compact design, integrated inlet baffle, and 'T' style design to minimize piping requirements. The filter is compliant with Federal procurement standards and tested for reliability in sterile environments.
Product Specifications
Benefits 0
Maintenance checks are simplified with visual inspectionsReduce downtime by eliminating need to shut down system to check filterTested to withstand impacts and fractures at full vacuum
Features And Specifications 0
Complete filter assembly is resistant to electrical static build-upHigh tensile strength permits dimensional stabilityIncreased holding capacityCompact design for space restrictions; Minimal service area neededIntegrated Inlet BaffleInlet is above the element to Extend element life and maintenance intervals"T" style design Minimizes piping requirements"Drop-Down" housing for easy servicing and dirt containmentCT Series with carbon steel buckets now available in 2", 2-1/2", 5" and 6" connections!
Specifications Bucket Material
Polycarbonate
Specifications Filter Type
Paper
Specifications Flow Rate
520 ft³/min
Specifications Maximum Complete Assembly Temperature Rating
220 ºF
Specifications Maximum See Through Bucket Temperature Rating
290 ºF
Specifications Size
4 in
Specifications Vacuum Level
1 x 103 mmHg | 1.3 x 1CV3 mbar
