4-Pin Board Mount Socket Connector
4-Pin Board Mount Socket Connector
SKU:PRO-8c0326
High-performance 4-pin board mount socket connector with durable construction and compliance with industry standards.
Regular price
$2.90
Regular price
Sale price
$2.90
Unit price
per
Initiate Order
4-Pin Board Mount Socket Connector
$2.90
Quantity: 1
Claim Your Seller Account
4-Pin Board Mount Socket Connector
$2.90
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4-Pin Board Mount Socket Connector is a versatile solution designed for high-performance connectivity. With a maximum AC/DC voltage of ~250V, this sensor connector ensures reliable power transmission. The terminal material of C5210 with Gold plating offers superior conductivity, while the Polycarbonate/ABS body (UL94V-0) provides durability. This connector is compliant with industry standards and suitable for various applications requiring a maximum current of 3.0A. Its robust construction, including a Fender Plated-Through Hole PCB, makes it ideal for institutional and government procurement needs.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Connector Type
Board Mount Socket
Specifications List Price
2.90 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Number Of Lines
4
Specifications Number Of Pins
4
Specifications Printed Circuit Board Pcb
Fender Plated-Through Hole
Specifications Printed Circuit Board Pcb Hole Diameter
1 mm
Specifications Printed Circuit Board Pcb Thickness
1.0 to 2.2 mm
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
