4" PVC Full Pattern Wafer Check Valve with 316 SS Spring & EPDM O-Ring

Name: 4" PVC Full Pattern Wafer Check Valve with 316 SS Spring & EPDM O-Ring
Brand: Stafford Manufacturing Corp.
SKU: QUI-3d41ba
Price: 149.99 USD
Availability: OutOfStock

SKU:QUI-3d41ba

High-performance 4" PVC Full Pattern Wafer Check Valve for robust flow control in diverse applications.

$149.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 4" PVC Full Pattern Wafer Check Valve from the WCV Series combines robust thermoplastic construction with high flow rates, eliminating the need for spacers or specialty flanges. With a pressure rating of 150 psi at 70°F, this valve features a 316 Stainless Steel spring, an EPDM O-Ring seal, and a wide pattern body that fits ANSI150 and PN10 flanges. Ideal for water treatment, chemical processing, marine environments, and more, this valve offers a high Cv rating equivalent to metal check valves, ensuring efficient and reliable performance.

Product Specifications

Dimensional Attributes Bore

16 mm

Dimensional Attributes Collar Boss Depth

0.125 in | 3.18 mm

Dimensional Attributes Collar Boss Height

0.15 in | 3.81 mm

Dimensional Attributes Collar Boss Width

0.265 in | 6.73 mm

Dimensional Attributes Collar Hub Od

1.005 in | 25.53 mm

Dimensional Attributes Collar Recess Dia

0.755 in | 19.18 mm

Dimensional Attributes Flange Od

2.375 in | 60.33 mm

Dimensional Attributes Flange Width

1/4 in | 6.35 mm

Dimensional Attributes Lever Hub Od

1.375 in | 34.93 mm

Dimensional Attributes Lever Relaxed Actual Gap

0.29 in | 7.37 mm

Dimensional Attributes Over All Width

1.03 in | 26.16 mm

Specifications Alloy

2024

Specifications Clamp Part

QC1A100P7

Specifications Country Of Origin

USA / Handle Made In China

Specifications Finish

None

Specifications Material

Aluminum

Specifications Maximum Axial Load

200 lb

Specifications Type

Python

4" PVC Full Pattern Wafer Check Valve with 316 SS Spring & EPDM O-Ring
