44 Series Twist Lock Standoff - Wire Routing Device

Name: 44 Series Twist Lock Standoff - Wire Routing Device
Brand: All Electronics Hardware
SKU: 03W-184f8b
Price: 24.99 USD
Availability: OutOfStock

SKU:03W-184f8b

Secure and elevate wire bundles effortlessly with the 44 Series Twist Lock Standoff in the .70-.80 range. RoHS compliant.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 44 Series Twist Lock Standoff is a reliable solution for routing and securing wires or bundles within the .70-.80 range with ease. Crafted from UL94V-2 Nylon 66 material, this standoff features an arrowhead snap lock for secure attachment to boards, elevating wires off panels to prevent interference with moving parts or heat sources. Its dimensions of .875" (L1) and 2.35" (L2) accommodate various bundle sizes, while the .156" hole size ensures compatibility across applications. This standoff not only meets RoHS standards but also enhances wire management efficiency for seamless installations.

Product Specifications

Specifications Bundle Diameter Range

.70 - .80 (17.8 - 20.0) inches (mm)

Specifications Dim L1

.875 (22.2) inches (mm)

Specifications Dim L2

2.35 (59.7) inches (mm)

Specifications Hole Size

.156 (4.0) inches (mm)

Specifications Material

UL94V-2 Nylon 66

Specifications Material Code

UL94V-2

Specifications Package Size

500 / bag
