45 Series Locking Wire Saddle Standoff

Name: 45 Series Locking Wire Saddle Standoff
Brand: All Electronics Hardware
SKU: 03W-b1009d
Price: 24.99 USD
Availability: OutOfStock

SKU:03W-b1009d

Top-tier wire routing solution with durable Nylon 66 construction, precise dimensions, and adaptable spacing heights for efficient cable management.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 45 Series Locking Wire Saddle Standoff is a top-tier wire routing solution designed for optimal cable management. Crafted from durable Nylon 66 material meeting UL94V-2 standards, this standoff features precise dimensions including a hole size of .187 inches, W2 dimension of .585 inches, L1 dimension of .500 inches, and L2 dimension of .930 inches. Its secure holding range of .189 x .420 inches ensures reliable cable fixation. The standout feature includes the ability to accommodate additional spacing heights, making it adaptable to varying requirements. Ideal for securing wires in place while maintaining organization and accessibility, this product is a must-have for efficient wire routing applications.

Product Specifications

Specifications Dim L1

.500 (12.7) inches (mm)

Specifications Dim L2

.930 (23.6) inches (mm)

Specifications Dim W2

.585 (14.9) inches (mm)

Specifications Holding Range W X W1

.189 x .420 (4.8 x 10.7) inches (mm)

Specifications Hole Size

.187 (4.8) inches (mm)

Specifications Material Code

UL94V-2

Specifications Remark

Additional spacing heights (L1) available-Inquiries welcome.
