48-Inch Urethane Compression Spring DT-35-48-11
48-Inch Urethane Compression Spring DT-35-48-11
SKU:URE-b816b5
High-performance 48-Inch Urethane Compression Spring DT-35-48-11 with corrosion resistance, high load capacity, and extended lifespan.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
48-Inch Urethane Compression Spring DT-35-48-11
$99.99
Quantity: 1
Claim Your Seller Account
48-Inch Urethane Compression Spring DT-35-48-11
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 48-Inch Urethane Compression Spring DT-35-48-11 is a top-quality solution for applications requiring resistance to corrosion, vibration, and magnetism. With a hardness of 80A duro and a length of 48 inches, this compression spring offers high load-carrying capability, non-magnetic properties, protection against marring, and extended lifespan. Designed for punching, stamping, and drawing dies, it provides excellent abrasion resistance, oil and solvent resistance, low noise operation, and effectiveness in temperatures ranging from -30°F to 180°F. Moreover, this urethane spring delivers vibration damping and shock absorbance for optimal performance.
Product Specifications
Specifications Additional Information
Polyurethane, however, is far more resistant to liquid and ozone attack. In fact, testing shows that polyurethane can be exposed to at least five times longer to the high levels of ozone specified for rubber in chapter 18 of the AREA manual (ASTM D1149) without deteriorative effects.
Specifications Continuous Cycle Per Hour
12,000
Specifications Continuous Maximum Deflection
0 to 15 %
Specifications Conventional Heavy Duty Steel Die Spring
0 to 500 lb
Specifications Cycles Per Hour For Slow Speeds Or Short Runs
200
Specifications Hardness
80A duro
Specifications Height
1 in
Specifications Intermittent Cycles Per Hour
700
Specifications Intermittent Maximum Deflection
0 to 25 %
Specifications Length
48 in
Specifications Maximum Deflection For Slow Speeds Or Short Runs
Less than 25%
Specifications Pressure Per 18 Inch In Deflection
16,400 lb
Specifications Product Features
High load-carrying capability | High dielectric strength and non-magnetic | Protection against marring/galling | Longer life | Abrasion resistance | Oil and solvent resistance | Low noise | 100% load-bearing surface | Bondable to mating parts | Effectiveness between - 30°F and 180°F | Vibration damping and shock absorbance
Specifications Shape
Bar
Specifications Urethane Bar Stock Weight
0 to 90,000 lb
Specifications Urethane Slab Stock Weight
Unlimited
Specifications Urethane Springs Weight
0 to 2,600 lb
Specifications Width
1.000 in
