5.0 kVDC Rated Standard Mica Capacitors
5.0 kVDC Rated Standard Mica Capacitors
SKU:HIG-1e8bc1
High performance 5.0 kVDC Rated Mica Capacitors for energy-efficient applications. Reliable and durable.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
5.0 kVDC Rated Standard Mica Capacitors
$39.99
Quantity: 1
Claim Your Seller Account
5.0 kVDC Rated Standard Mica Capacitors
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our 5.0 kVDC Rated Standard Mica Capacitors are precision-engineered for high energy applications. With a capacitance of 50nF and a ±10% tolerance, these capacitors ensure reliable performance. Featuring a dissipation factor of 0.005 at 25°C, high insulation resistance, and a dielectric withstanding voltage of 10.0 kV, they meet stringent quality standards. These capacitors are mylar wrapped, epoxy end-capped, with AWG 18 solder-coated copper wire leads for durability and safety. Ideal for both consumer electronics and institutional settings, these capacitors guarantee superior performance and longevity.
Product Specifications
Cable Preparation Insulation Resistance
25 MΩ*µF at125°C, need not exceed 1GΩ | 4000 MΩ*µF at25°C, need not exceed 100GΩ
Specifications Capacitance
50 nF
Specifications Capacitance Tolerance
±10%
Specifications Dielectric Withstanding Voltage
10.0 kV proof for 5 seconds | 5 kV rated | 7.5 kV burn-in for 2 hours at 100°C
Specifications Dissipation Factor
0.005 Max. at 25°C, 1 kHZ
Specifications Length
2.56 in | 65.0 mm
Specifications Standardnon Standard
Standard Part
Specifications Thickness
0.26 in | 6.6 mm
Specifications Voltage Rating
5 kVDC
Specifications Width
1.62 in | 41.1 mm
