5.0 kVDC Rated Standard Micapacitors
5.0 kVDC Rated Standard Micapacitors
SKU:HIG-e69a7f
High-performance 5.0 kVDC Rated Standard Micapacitors with 10 nF capacitance, ±10% tolerance, and 10.0 kV proof voltage. Ideal for high energy applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
5.0 kVDC Rated Standard Micapacitors
$29.99
Quantity: 1
Claim Your Seller Account
5.0 kVDC Rated Standard Micapacitors
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 5.0 kVDC Rated Standard Micapacitors are precision components designed for high energy devices, specifically in the High Voltage Mica Capacitors category. With a capacitance of 10 nF and a capacitance tolerance of ±10%, these capacitors provide reliable performance with a low dissipation factor of 0.005 Max. at 25°C, 1 kHZ. They boast a dielectric withstanding voltage of 10.0 kV proof for 5 seconds, making them ideal for demanding applications. Additionally, the insulation resistance values ensure optimal functionality at varying temperatures. These standard parts are mylar wrapped, epoxy endcapped, and feature wire leads for easy installation. Safety is prioritized as the capacitors are shipped with leads shorted, meeting essential regulatory requirements.
Product Specifications
Cable Preparation Insulation Resistance
25 MΩ*µF at125°C, need not exceed 1GΩ | 4000 MΩ*µF at25°C, need not exceed 100GΩ
Specifications Capacitance
10 nF
Specifications Capacitance Tolerance
±10%
Specifications Dielectric Withstanding Voltage
10.0 kV proof for 5 seconds | 5 kV rated | 7.5 kV burn-in for 2 hours at 100°C
Specifications Dissipation Factor
0.005 Max. at 25°C, 1 kHZ
Specifications Length
1.69 in | 42.9 mm
Specifications Standardnon Standard
Standard Part
Specifications Thickness
0.20 in | 5.1 mm
Specifications Voltage Rating
5 kVDC
Specifications Width
0.97 in | 24.6 mm
