5-Pole Light Blue Female Connector - 20A, Outdoor Rated

Name: 5-Pole Light Blue Female Connector - 20A, Outdoor Rated
Brand: Wieland Electric Inc.
SKU: CIR-9b0913
Price: 24.99 USD
Availability: OutOfStock

SKU:CIR-9b0913

Robust 5-Pole Female Connector - 20A, Outdoor Rated, Easy Installation

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 5-Pole Light Blue Female Connector is a robust outdoor-rated electrical connector designed for reliability and durability. With a screw connection type and angled 90º plug for easy installation, this connector ensures secure connections in various environments. It supports a rated current of 20 A and can accommodate cables ranging from 6mm to 10mm in diameter. Meeting IP69 and Type 4X/6P protection standards, this connector is suitable for diverse applications requiring a high level of performance and safety.

Product Specifications

Note Note

Technical details are subject to change

Specifications Angle Of Plug

Angled 90Âº

Specifications Color Of Codingcontact Carrier

Light Blue

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Female

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

10 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

6 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²

5-Pole Light Blue Female Connector - 20A, Outdoor Rated
