5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
SKU:CIR-ea3091
High-quality 5-Pole Light Blue Female Connector - IP69 & Type 4X/6P rated, 20A current, IEC & cULus standards
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
$24.99
Quantity: 1
Claim Your Seller Account
5-Pole Light Blue Female Connector - 20A Pluggable Electrical Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 5-Pole Light Blue Female Connector is a high-quality pluggable electrical connector designed for reliable outdoor use. Featuring an angled 90° plug for easy installation, this connector is IP69 and Type 4X/6P rated, ensuring protection against water and dust. With a rated current of 20A and compatibility with cable diameters ranging from 10mm to 14mm, this connector meets stringent international standards such as IEC and cULus for wire size, voltage, and current rating. Trust in the durability and performance of this connector for your electrical connections.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Angled 90º
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
5
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
