5-Pole Light Blue Female Connector - 4/5 Poles, 20A

Name: 5-Pole Light Blue Female Connector - 4/5 Poles, 20A
Brand: Wieland Electric Inc.
SKU: CIR-fea6da
Price: 24.99 USD
Availability: OutOfStock

SKU:CIR-fea6da

High-quality 20A 5-Pole Female Connector for outdoor use, IP69 & Type 4X/6P protection, meets IEC & cULus standards.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 5-Pole Light Blue Female Connector is a high-quality, pluggable electrical connector designed for outdoor applications. With a straight angle of plug and screw connection type, it offers secure connections. Rated for 20A and compatible with cable diameters ranging from 10mm to 14mm, this connector meets IEC and cULus standards. Its IP69 and Type 4X/6P protection ensure durability in harsh environments. Trust Wieland brand for reliable compliance and performance.

Product Specifications

Note Note

Technical details are subject to change

Specifications Angle Of Plug

Straight

Specifications Color Of Codingcontact Carrier

Light Blue

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Female

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

14 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

10 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²
