5-Pole Light Gray Male Connector for Outdoor Use - 20A

Name: 5-Pole Light Gray Male Connector for Outdoor Use - 20A
Brand: Wieland Electric Inc.
SKU: CIR-2c80b2
Price: 24.99 USD
Availability: OutOfStock

SKU:CIR-2c80b2

Reliable 5-pole male connector with IP69 protection for outdoor use. Rated at 20A, suitable for various cable sizes.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 5-Pole Light Gray Male Connector is designed for outdoor applications, featuring a sturdy screw connection and IP69 protection. With a rated current of 20A and compatibility with cables ranging from 6mm to 10mm in diameter, this Wieland connector ensures reliable power distribution. Meeting international standards like IEC and North American cULus requirements, this connector is ideal for both consumer and institutional installations.

Product Specifications

Note Note

Technical details are subject to change

Specifications Angle Of Plug

Straight

Specifications Color Of Codingcontact Carrier

Light Gray

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Male

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

10 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

6 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²
