5-Pole Turquoise Blue Female Connector - 20A

Name: 5-Pole Turquoise Blue Female Connector - 20A
Brand: Wieland Electric Inc.
SKU: CIR-e5a674
Price: 29.99 USD
Availability: OutOfStock

SKU:CIR-e5a674

High-quality 5-pole turquoise blue female connector for outdoor use, 20A rated current, IP69 & Type 4X/6P rated.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 5-Pole Turquoise Blue Female Connector is a high-quality pluggable electrical connector designed for outdoor applications. With a rated current of 20A, this connector is manufactured by Wieland and features a screw connection type for secure and reliable installations. It is IP69 and Type 4X/6P rated, ensuring protection against environmental elements. Suitable for cables ranging from 10mm to 14mm in diameter, this connector meets international standards for voltage and wire size.

Product Specifications

Note Note

Technical details are subject to change

Specifications Angle Of Plug

Angled 90Âº

Specifications Color Of Codingcontact Carrier

Turquoise Blue

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Female

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

14 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

10 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²
