50 Ohm SMA Termination, Female Jack Connector

Name: 50 Ohm SMA Termination, Female Jack Connector
Brand: C. W. Swift & Associates, Inc.
SKU: SMA-a4b305
Price: 29.99 USD
Availability: OutOfStock

SKU:SMA-a4b305

High-quality 50 ohm SMA termination with gold-plated female jack connector for optimal impedance control and performance. VSWR ratings from DC to 18 GHz.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 50 ohm SMA Termination, Female Jack Connector is a high-quality, gold-plated termination designed for precise impedance control in SMA connector systems. With ultra-low VSWR ratings across multiple frequency ranges, from DC up to 18 GHz, this termination ensures minimal signal reflections and optimal performance. Suitable for various applications requiring stable impedance matching, the SMA termination is a reliable solution that meets stringent industry standards.

Product Specifications

Specifications Configuration

termination

Specifications Connection

female

Specifications Connector Series

SMA

Specifications Impedence Ohms

Specifications Packaging

single

Specifications Plating Body

gold

Specifications Vsrw 14 18 Ghz F

1.25

Specifications Vswr 10 14 Ghz F

1.15

Specifications Vswr 4 10 Ghz F

1.1

Specifications Vswr Dc 4 Ghz F

1.05
