50 Ohm Straight PCB Plugs (Male)
50 Ohm Straight PCB Plugs (Male)
SKU:MCX-ecfaea
High-performance 50 Ohm Straight PCB Plugs (Male) for reliable, low-resistance connectivity in high-frequency applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
50 Ohm Straight PCB Plugs (Male)
$29.99
Quantity: 1
Claim Your Seller Account
50 Ohm Straight PCB Plugs (Male)
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 50 Ohm Straight PCB Plugs (Male) are part of the MCX Subminiature Connector series by HUBER+SUHNER, designed for optimal performance in high-frequency applications. With gold-plated bodies for enhanced connectivity, these connectors offer a straight configuration with a .100-inch grid for seamless integration. Meeting stringent industry standards, including durable materials such as brass, beryllium copper, and PTFE insulation, these connectors ensure reliable connections with minimal resistance. Suitable for a wide temperature range from -67 to 311 degrees Fahrenheit, these plugs deliver exceptional performance and durability for demanding environments.
Product Specifications
Specifications Body Material
Brass
Specifications Centre Contact Resistance M Ohms
<5
Specifications Configuration
straight
Specifications Connection
male
Specifications Connector Series
MCX
Specifications Contact Captivation Lbs
>2.3
Specifications Crimp Ferrule Material
Copper
Specifications Dielectic Withstanding Voltage Sea Level V Rms
>750
Specifications Disengagement Force Lbs
1.8 to 4.5
Specifications Durability Matings
>500
Specifications Engagement Force Lbs
<5.6
Specifications Frequency Ghz
DC...6
Specifications Grid Inches
.100
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>100000
Specifications Insulator Material
PTFE or PFA
Specifications Mount
with standoff
Specifications Mounting Hole
ML 15
Specifications Outer Contacts Jack
Brass
Specifications Outer Contacts Plug
Beryllium copper, hardened
Specifications Outside Contact Resistance M Ohms
<1
Specifications Packaging
bulk 100 pcs.
Specifications Pin Contact Material
Brass
Specifications Plating Body
gold
Specifications Rf Leakage Connectors For Flexible Cables Db
>60
Specifications Rf Leakage Connectors For Semi Rigid Cables Db
>70
Specifications Socket Contact Material
Beryllium copper, hardened
Specifications Temperature Range Degrees F
-67 to 311
Specifications Working Voltage 70000 Ft V Rms
>42
Specifications Working Voltage Sea Level V Rms
>170
