500A Solid Copper Bar with Clamped Joints

500A Solid Copper Bar with Clamped Joints

SKU:CRA-570197

High-performance 500A Solid Copper Bar with Clamped Joints for crane control & electrification. Durable, efficient, and easy to install.

Regular price $299.99
Regular price Sale price $299.99
Sale

Initiate Order

500A Solid Copper Bar with Clamped Joints

500A Solid Copper Bar with Clamped Joints

$299.99

Quantity: 1

Claim Your Seller Account

500A Solid Copper Bar with Clamped Joints

500A Solid Copper Bar with Clamped Joints

$299.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 500A Solid Copper Bar with Clamped Joints is precision roll-formed from 1/32" solid copper material, ensuring exceptional durability and conductivity for crane control and electrification applications. Featuring a uniform 1" x 1/4" equivalent rectangle profile, it boasts an impressive ampacity of 500A with low resistance (40 µΩ/ft) and efficient impedance characteristics. Each 20' length is equipped with rigid PVC covers, connector clamps, and cases, making installation and maintenance hassle-free. With a weight of 23.6 lb and a compact cross-sectional area of 0.1477 in², this copper bar with clamped joints is designed to meet the rigorous demands of industrial settings.

Product Specifications

Electrical Data Ampacity Continuous Duty
500 A
Electrical Data Impedance Z 60hz
70 µΩ/ft
Electrical Data Reactance X 60 Hz
60 µΩ/ft
Electrical Data Resistance R For Dc At 20 C
40 µΩ/ft
Specifications Cover Type
Rigid PVC
Specifications Cross Sectional Area
0.1477 in²
Specifications Expansion Coefficient
0.000009 ºF
Specifications Length
20 ft
Specifications Material
Solid Copper
Specifications Normal Ambient
-10 to 160 ºF
Specifications Support Spacing
5 ft
Specifications Weight
23.6 lb | 0.16 lb/ft
