500A Solid Copper Bar with Clamped Joints
500A Solid Copper Bar with Clamped Joints
SKU:CRA-0bf76a
High-conductivity 500A Solid Copper Bar with Clamped Joints for secure connections and durability. Ideal for crane control & conductor bar systems.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
500A Solid Copper Bar with Clamped Joints
$249.99
Quantity: 1
Claim Your Seller Account
500A Solid Copper Bar with Clamped Joints
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your electrical system with the 500A Solid Copper Bar featuring clamped joints for secure connections. Made of solid copper, this bar ensures high conductivity and durability. With an ampacity of 500A and low resistance at 40 µΩ/ft, it meets rigorous electrical standards. The 20 ft length with medium heat cover and minimal expansion coefficient makes it ideal for various applications. Suitable for crane control, electrification, and conductor bar systems, this product offers reliable performance and ease of installation.
Product Specifications
Electrical Data Ampacity Continuous Duty
500 A
Electrical Data Impedance Z 60hz
70 µΩ/ft
Electrical Data Reactance X 60 Hz
60 µΩ/ft
Electrical Data Resistance R For Dc At 20 C
40 µΩ/ft
Specifications Cover Type
Medium Heat
Specifications Cross Sectional Area
0.1477 in²
Specifications Expansion Coefficient
0.000009 ºF
Specifications Length
20 ft
Specifications Material
Solid Copper
Specifications Normal Ambient
-25 to 250 ºF
Specifications Support Spacing
5 ft
Specifications Weight
22.1 lb | 0.16 lb/ft
