500A Solid Copper Bar with Clamped Joints
500A Solid Copper Bar with Clamped Joints
SKU:CRA-bbf37b
Enhance power transmission with the 500A Solid Copper Bar trimmed with Clamped Joints
Regular price
$229.99
Regular price
Sale price
$229.99
Unit price
per
Initiate Order
500A Solid Copper Bar with Clamped Joints
$229.99
Quantity: 1
Claim Your Seller Account
500A Solid Copper Bar with Clamped Joints
$229.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 500A Solid Copper Bar with Clamped Joints is expertly roll-formed with 1/32" solid copper material, providing exceptional durability and conductivity. With an ampacity of 500A and low resistance of 40 µΩ/ft, this conductor bar ensures efficient power transmission. Designed for crane control and electrification applications, it meets industry standards for support spacing, cover type, and expansion coefficient. Each 20' length comes complete with connector clamps and a protective case, offering easy installation and replacement.
Product Specifications
Electrical Data Ampacity Continuous Duty
500 A
Electrical Data Impedance Z 60hz
70 µΩ/ft
Electrical Data Reactance X 60 Hz
60 µΩ/ft
Electrical Data Resistance R For Dc At 20 C
40 µΩ/ft
Specifications Cover Type
Medium Heat
Specifications Cross Sectional Area
0.1477 in²
Specifications Expansion Coefficient
0.000009 ºF
Specifications Length
5 ft
Specifications Material
Solid Copper
Specifications Normal Ambient
-25 to 250 ºF
Specifications Support Spacing
5 ft
Specifications Weight
11.0 lb | 0.16 lb/ft
