500A Solid Copper Bar with Clamped Joints
500A Solid Copper Bar with Clamped Joints
SKU:CRA-75800f
Efficient 500A Solid Copper Bar with clamped joints for reliable crane control & electrification.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
500A Solid Copper Bar with Clamped Joints
$129.99
Quantity: 1
Claim Your Seller Account
500A Solid Copper Bar with Clamped Joints
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 500A Solid Copper Bar is expertly roll formed from 1/32' thick material, with a 1' x 1/4' rectangle profile ensuring efficient conductivity. This conductor bar system supports continuous duty up to 500A, with low resistance at 40 µΩ/ft for DC applications. Clamped joints, rigid PVC covers, and a weight of 11.8 lb make it a reliable choice for crane control & electrification needs. With a temperature range of -10 to 160°F, this 5 ft long bar meets industry standards for performance and longevity.
Product Specifications
Electrical Data Ampacity Continuous Duty
500 A
Electrical Data Impedance Z 60hz
70 µΩ/ft
Electrical Data Reactance X 60 Hz
60 µΩ/ft
Electrical Data Resistance R For Dc At 20 C
40 µΩ/ft
Specifications Cover Type
Rigid PVC
Specifications Cross Sectional Area
0.1477 in²
Specifications Expansion Coefficient
0.000009 ºF
Specifications Length
5 ft
Specifications Material
Solid Copper
Specifications Normal Ambient
-10 to 160 ºF
Specifications Support Spacing
5 ft
Specifications Weight
11.8 lb | 0.16 lb/ft
