5086-H34 Aluminum Tread Sheet and Plate
5086-H34 Aluminum Tread Sheet and Plate
SKU:ALU-cd4ec9
Enhance projects with 5086-H34 Aluminum Tread Sheet & Plate: high-strength, corrosion-resistant alloy for various applications.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
5086-H34 Aluminum Tread Sheet and Plate
$349.99
Quantity: 1
Claim Your Seller Account
5086-H34 Aluminum Tread Sheet and Plate
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your projects with the 5086-H34 Aluminum Tread Sheet and Plate. This high-strength alloy offers superior weldability, excellent corrosion resistance, and optimal design efficiency. With a thickness of 0.25 inches and ultimate strength of 47 ksi, it is ideal for unfired pressure vessels, heavy-duty truck assemblies, boat hulls, and more.
Product Specifications
Aluminum Alloy Designations 0
The aluminum industry uses a four-digit index system for the designation of its wrought aluminum alloys.As outlined below, the first digit indicates the alloy group according to the major alloying elements.1xxx SeriesIn this group minimum aluminum content is 99% and there is no major alloying element. The second digit indicates modifications in impurity limits. If the second digit is zero, there is no special control on individual impurities. Digits 1 through 9, which are assigned consecutively as needed, indicate special control of one or more individual impurities. The last two digits indicate specific minimum aluminum content. Although the absolute minimum aluminum content in this group is 99%, the minimum for certain grades is higher than 99%, and the last two digits represent the hundredths of a per cent over 99. Thus, 1030 would indicate 99.30% minimum aluminum. without special control on individual impurities. The designations 1130, 1230, 1330, etc.. indicate the same purity with special control on one or more impurities. Likewise 1100 indicates minimum aluminum content of 99.00% with individual impurity control.2xxx through 9xxx SeriesThe major alloying elements are indicated by the first digit, as follows: 2xxx Copper3xxx Manganese4xxx Silicon5xxx Magnesium6xxx Magnesium and silicon7xxx Zinc8xxx Other element9xxx Unused seriesThe second digit indicates alloy modification. If the second digit is zero. it indicates the original alloy: digits 1 through 9, which are assigned consecutively, indicate alloy modifications. The last two digits have no special significance, serving only to identify the different alloys in the group.Experimental AlloysExperimental alloys are designated according to the four digit system, but they are prefixed by the letter X. The prefix is dropped when the alloy becomes standard. During development, and before they are designated as experimental, new alloys are identified by serial numbers assigned by their originators. Use of the serial number is discontinued when the X number is assigned.
Comparative Characteristics And Applications Applications
Unfired, welded pressure vessels, marine, auto aircraft cryogenics, TV, towers, drilling rigs, transportation, equipment, missile components
Comparative Characteristics And Applications Arc Weldability
A
Comparative Characteristics And Applications Brazeability
D
Comparative Characteristics And Applications Gas Weldability
C
Comparative Characteristics And Applications Mechinability
C
Comparative Characteristics And Applications Resistance Spot And
A
Comparative Characteristics And Applications Resistance To Corro
A
Comparative Characteristics And Applications Stress Corrosion Cr
B
Comparative Characteristics And Applications Workability Cold
B
Specifications Density
0.096 lbs/in³
Specifications Grade
5086
Specifications Length
192
Specifications Material
Aluminum
Specifications Series
5086-H34
Specifications Shapeform
Plates
Specifications Sheet Weight Per Unit Area
3.586 lbs/ft² | 17.506852 kg/m²
Specifications Size
60 x 192
Specifications Specific Gravity
2.66
Specifications Temper
H34
Specifications Thickness
0.25 inches | 6.25 mm
Specifications Weight Per Plate
286.88 lbs | 129.95664 kg
Specifications Width
60
Mechanical Properties Elongation Percent In 2 Inches
10
Mechanical Properties Modulus Of Elasticity
10.3 x 102 ksi
Mechanical Properties Ultimate Shearing Strength
27 ksi
Mechanical Properties Ultimate Strength
47 ksi
Mechanical Properties Yield Strength
37 ksi
