The 521 Series Plug Kit is a high voltage connector designed for maximum user safety, featuring recessed contacts that minimize the risk of electrical shock. With a voltage rating of 25 kVDC at 70,000 ft and a test voltage of 41 kVDC at the same altitude, this kit ensures secure electrical connections even in demanding conditions. The bayonet coupling style, brass coupling nut, and crimp braid termination provide reliable performance, while the spring finger body contact enhances the ground circuit for added safety. Operating between -40 to 85°C, this kit is ideal for high voltage applications requiring precision and safety.
Product Specifications
Coupling Nut Properties Bayonet Coupling Nut Finish
Nickel
Coupling Nut Properties Bayonet Coupling Nut Material
Brass
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Plug Bag Assembly
Specifications Braid Termination
Crimp
Specifications Coupling Style
Bayonet
Specifications Current Rating
20 A
Specifications Export Classification
TBD
Specifications Operating Temperature
-40 to 85 ºC
Specifications Plug Contact Materialfinish
BeCu/Au
Specifications Plug Insulator Material
Plastic
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
521
Specifications Test Voltage 70000 Ft
41
Specifications Test Voltage At Sea Level
28 kVDC
Specifications Voltage Rating
25 kVDC
Specifications Wire Insulation
PE
Specifications Wire Type
Shielded
