5kVDC Single Pin Stub Cable Assembly (Male)
5kVDC Single Pin Stub Cable Assembly (Male)
SKU:HIG-984a2c
Highly reliable 5kVDC Single Pin Stub Cable Assembly for Aerospace/Defense and commercial applications. Mates with all Series 600 plug assemblies. Brass coupling nut with gold plating. BeCu contacts with gold finish. Temp range: -55 to 125 ºC.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
5kVDC Single Pin Stub Cable Assembly (Male)
$49.99
Quantity: 1
Claim Your Seller Account
5kVDC Single Pin Stub Cable Assembly (Male)
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 600 Series 5kVDC Single Pin Stub Cable Assembly (Male) is a highly reliable, subminiature coaxial connector suitable for Aerospace/Defense and commercial applications. With a voltage rating of 5 kVDC and an altitude tolerance up to 70,000 ft., this assembly excels in high-stress environments. Featuring a brass coupling nut with gold plating, BeCu contacts with gold finish, and a temperature range of -55 to 125 ºC, this assembly ensures robust performance. Mates with all Series 600 plug assemblies, offering seamless compatibility and a current rating of 1 Amp, meeting strict industry standards.
Product Specifications
Body Properties Coupling Nut Finish
Gold Plated
Body Properties Coupling Nut Material
Brass
Contact Properties Contact Finish
Gold
Contact Properties Contact Material
BeCu
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Single-Ended Receptacle Cable Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
1 Amp
Specifications End 1
1674440
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Lock Wire Holes In Coupling Nut
No
Specifications Mating Compatibility
Mates all Series 600 plug assemblies
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
600
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
7.5 kVDC at 70,000 ft. (simulated) at ambient temperature
Specifications Voltage Rating
5 kVDC
