SKU:ALU-50b0a8
Premium 5mm Aluminum/Magnesium/Silicon Alloy Rod with superior mechanical & thermal properties. Ideal for diverse applications.
Regular price
$25.99
Regular price
Sale price
$25.99
Unit price
per
Initiate Order
5mm Aluminum/Magnesium/Silicon Alloy Rod - Goodfellow Corp.
$25.99
Quantity: 1
Claim Your Seller Account
5mm Aluminum/Magnesium/Silicon Alloy Rod - Goodfellow Corp.
$25.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 5mm Aluminum/Magnesium/Silicon Alloy Rod by Goodfellow Corp. is a premium choice for both consumer and institutional needs. This straight length rod boasts superior mechanical properties including a modulus of elasticity of 69.5 GPa and a tensile strength ranging from 90.00 to 300.00 MPa. With a low electrical resistivity of 3.2 µΩ·cm and excellent thermal conductivity at 209.00 W m-1K-1, this rod ensures efficient performance in various applications. Compliant with industry standards and precise tolerances, this alloy rod guarantees reliability and durability for your projects.
Product Specifications
Electrical Properties Electrical Resistivity
3.2 µΩ·cm
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 16.0 %
Mechanical Properties Modulus Of Elasticity
69.5 GPa
Mechanical Properties Tensile Strength
90.00 to 300.00 MPa
Physical Properties Density
2.700 g·cm-3
Specifications Diameter
5 mm
Specifications Form
Rod
Specifications Length
100 to 1000 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.400 x10-6 K-1
Thermal Properties Melting Point
655.00 ºC
Thermal Properties Specific Heat At 23 Degree Celsius C Temperat
960.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
209.00 W m-1K-1
Tolerances Tolerance For 100 Millimeter Mm Length Round
-1 % | +5 %
Tolerances Tolerance For 10 Millimeter Mm Diameter
5 %
Tolerances Tolerance For 10 Millimeter Mm Diameter
10 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
