6.35mm Aluminum Magnesium Silicon Tube
6.35mm Aluminum Magnesium Silicon Tube
SKU:ALU-d924af
High-strength 6.35mm Al/Mg/Si Tube by Goodfellow Corp. for reliable performance in varied applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
6.35mm Aluminum Magnesium Silicon Tube
$49.99
Quantity: 1
Claim Your Seller Account
6.35mm Aluminum Magnesium Silicon Tube
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 6.35mm Outside Diameter Aluminum/Magnesium/Silicon Tube, manufactured by Goodfellow Corp., offers exceptional strength and durability for various applications. With a precise wall thickness of 0.71mm and an inside diameter of 4.93mm, this tube is engineered for hardness and reliability. It exhibits a Brinell hardness of 65 to 95 and a modulus of elasticity of 69.0 GPa, ensuring optimal performance under pressure. Its thermal conductivity of 180.00 to 195.00 W m-1K-1 makes it suitable for thermal applications while meeting strict standards for electrical resistivity and thermal expansion. This tube is ideal for government, institutional, and commercial procurement where quality and precision are non-negotiable.
Product Specifications
Electrical Properties Electrical Resistivity
3.4 to 3.8 µΩ·cm
Electrical Properties Temperature Coefficient
0.00310 to 0.00350 k-1
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 20.0 %
Mechanical Properties Hardness Brinell
65 to 95
Mechanical Properties Modulus Of Elasticity
69.0 GPa
Mechanical Properties Tensile Strength
245.00 to 325.00 MPa
Physical Properties Density
2.690 g·cm-3
Specifications Form
Tube
Specifications Inside Diameter
4.93 mm
Specifications Length
100 to 1000 mm
Specifications Outside Diameter
6.35 mm
Specifications Temper
Hard
Specifications Wall Thickness
0.71 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.000 x10-6 K-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
180.00 to 195.00 W m-1K-1
Tolerances Tolerance For 100 Millimeter Mm Length Round
-1 % | +5 %
Tolerances Tolerance For 2 Millimeter Mm Outside Diameter
0.5 mm
Tolerances Tolerance For 5 Millimeter Mm Outside Diameter
5 %
Tolerances Wall Thickness Tolerance
10 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
