The 6-Inch Bore Size Air Powered Intensifiers from Compact Automation Products' CI Series deliver exceptional pressure intensification, with maximum output pressures ranging from 1800 to 4900 psi. Designed for efficiency and durability, these intensifiers feature rugged yet lightweight aluminum construction, ensuring long-lasting performance with low friction. With options like the optional Magnetic piston for enhanced functionality, these intensifiers offer reliability and precision in hydraulic systems.

Product Specifications

Features Features
Rugged space efficient, low weightAluminum designLong life/Low frictionThree mounting choicesOptional Magnetic piston (Option "ACI")
Specifications Construction Material
Aluminum | Other
Specifications High Pressure Hp Outlet Bore Size High
2 in
Specifications High Pressure Hp Outlet Bore Size Low
1.125 in
Specifications Maximum Outlet Flow High
9 in³/min
Specifications Maximum Outlet Flow Low
1 in³/min
Specifications Maximum Output Pressure High
4900 psi
Specifications Maximum Output Pressure Low
1800 psi
Specifications Oil Based Hydraulic Fluid
Yes
Specifications Piston Travel High
3 in
Specifications Piston Travel Low
1 in
Specifications Pneumatic
Yes
Specifications Pressure Inlet Bore Size Low
6 in
Specifications Pressure Intensification Factor High
28
Specifications Pressure Intensification Factor Low
9
Specifications Series
CI Series
