6" PPL Swing Check Valve with EPDM Seals, Flanged End Connections

Name: 6" PPL Swing Check Valve with EPDM Seals, Flanged End Connections
Brand: Stafford Manufacturing Corp.
SKU: QUI-053245
Price: 499.99 USD
Availability: OutOfStock

SKU:QUI-053245

Enhance fluid control with the 6" Swing Check Valve - superior performance and durability for various applications.

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your fluid control system with the 6" PPL Swing Check Valve from the Hayward SW Series. Crafted from durable PPL material with EPDM seals, this valve offers superior temperature/pressure ratings, outperforming traditional plastic valves. Suitable for horizontal or vertical installation, it features a counterweight or spring for controlled closing. With precision engineering and reliable flanged end connections, this valve ensures seamless flow regulation and longevity in diverse applications.

Product Specifications

Dimensional Attributes Bore

8 mm

Dimensional Attributes Collar Boss Depth

0.125 in | 3.18 mm

Dimensional Attributes Collar Boss Height

0.15 in | 3.81 mm

Dimensional Attributes Collar Boss Width

0.250 in | 6.35 mm

Dimensional Attributes Collar Hub Od

0.755 in | 19.18 mm

Dimensional Attributes Collar Recess Dia

0.440 in | 11.18 mm

Dimensional Attributes Flange Od

2.1 in | 53.34 mm

Dimensional Attributes Flange Width

1/4 in | 6.35 mm

Dimensional Attributes Lever Hub Od

1.1 in | 27.94 mm

Dimensional Attributes Lever Relaxed Actual Gap

0.275 in | 6.99 mm

Dimensional Attributes Over All Width

1.03 in | 26.16 mm

Specifications Alloy

2024

Specifications Clamp Part

QC1A012P7

Specifications Country Of Origin

USA / Handle Made In China

Specifications Finish

None

Specifications Material

Aluminum

Specifications Maximum Axial Load

200 lb

Specifications Type

Python

6" PPL Swing Check Valve with EPDM Seals, Flanged End Connections
