6" PVC Full Pattern Wafer Check Valve with HASTELLOY Spring

Name: 6" PVC Full Pattern Wafer Check Valve with HASTELLOY Spring
Brand: Stafford Manufacturing Corp.
SKU: QUI-457ec9
Price: 299.99 USD
Availability: OutOfStock

SKU:QUI-457ec9

Revolutionary PVC Full Pattern Wafer Check Valve with HASTELLOY Spring, ANSI150/PN10, High Cv Rating, Suitable for Various Industries

$299.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The WCV Series Full Pattern Wafer Check Valve is a revolutionary solution for various industries. Constructed from PVC, it boasts a robust wide pattern body that eliminates the need for spacers or specialty flanges. With a high Cv rating equal to metal check valves, it offers optimal flow capacity with a lower closing pressure than swing check valves. Designed for ANSI150 and PN10 flanges, this valve is pressure rated to 150 PSI, making it ideal for water and wastewater treatment, chemical processing, and marine environments. Additionally, its FPM o-ring seals ensure reliable performance in a wide range of applications.

Product Specifications

Dimensional Attributes Bore

25 mm

Dimensional Attributes Collar Boss Depth

0.125 in | 3.18 mm

Dimensional Attributes Collar Boss Height

0.15 in | 3.81 mm

Dimensional Attributes Collar Boss Width

0.335 in | 8.51 mm

Dimensional Attributes Collar Hub Od

1.255 in | 31.88 mm

Dimensional Attributes Collar Recess Dia

1.1093 in | 28.18 mm

Dimensional Attributes Flange Bolt Circle Dia

2.362 in | 59.99 mm

Dimensional Attributes Flange C Bore Depth

0.246 in | 6.25 mm

Dimensional Attributes Flange C Bore Dia

0.438 in | 11.13 mm

Dimensional Attributes Flange Od

2.953 in | 75.01 mm

Dimensional Attributes Flange Thread

M6 X 1

Dimensional Attributes Flange Thru Dia

0.25 in | 6.35 mm

Dimensional Attributes Flange Width

0.445 in | 11.30 mm

Dimensional Attributes Keyway Width

0.315 in | 8.00 mm

Dimensional Attributes Lever Hub Od

1.625 in | 41.28 mm

Dimensional Attributes Lever Relaxed Actual Gap

0.36 in | 9.14 mm

Dimensional Attributes Over All Width

1.225 in | 31.12 mm

Specifications Alloy

2024

Specifications Clamp Part

QC1A104P7

Specifications Country Of Origin

USA / Handle Made In China

Specifications Finish

None

Specifications Material

Aluminum

Specifications Maximum Axial Load

200 lb

Specifications Type

Python

6" PVC Full Pattern Wafer Check Valve with HASTELLOY Spring
