The 600 SL Series Non-Sealed Front Panel Mount Receptacle is a subminiature, high voltage connector designed for reliability in Aerospace/Defense and commercial applications. With a Voltage Rating of 10 kVDC, Current Rating of 1 Amp, and operating temperature range of -55 to 125 °C, this connector ensures secure connections in various environments. The brass Coupling Nut with Gold Plating and BeCu Contact Material provide durability and performance, making it ideal for high voltage applications requiring precision and stability.
Product Specifications
Body Properties Coupling Nut Finish
Gold Plated
Body Properties Coupling Nut Material
Brass
Contact Properties Contact Diameter
0.031 in | 0.79 mm
Contact Properties Contact Finish
Gold
Contact Properties Contact Material
BeCu
Specifications Altitudereduced Pressure Rating
Sea Level
Specifications Assembly Type
Receptacle Bag Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
1 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Lock Wire Holes In Coupling Nut
No
Specifications Mating Compatibility
Mates all Series 600 SL plug assemblies
Specifications Mating Torque
4 to 6 in-lbs
Specifications Mounting
Requires .197 (5.0 mm) diameter hole
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Front Mount
Specifications Panel Mounting Torque
8 to 10 in-lbs
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
600 SL
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
15 kVDC at Sea Level
Specifications Voltage Rating
10 kVDC
