The 610 Series Receptacle is designed with a larger coupling nut and specialized threads for reliable performance in airborne and high mating operation scenarios. Featuring an altitude sealing capability up to 70,000 ft. and a wide operating temperature range of -55°C to +125°C, this receptacle ensures optimal functionality in demanding environments. With a current rating of 1 Amp, gold-plated brass coupling nut, and Beryllium Copper contacts, it offers secure connections and durability. Mates exclusively with Series 610 plugs, enhancing safety in multiple circuit applications.
Product Specifications
Body Properties Coupling Nut Finish
Gold Plated
Body Properties Coupling Nut Material
Brass
Contact Properties Contact Diameter
0.031 in | 0.79 mm
Contact Properties Contact Finish
Gold
Contact Properties Contact Material
BeCu
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Receptacle Bag Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
1 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Lock Wire Holes In Coupling Nut
No
Specifications Mating Compatibility
Mates all Series 610 plug assemblies only
Specifications Mating Torque
3 to 4 in-lbs
Specifications Mounting
Requires .197 (5.0 mm) dia. hole
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Front Mount
Specifications Panel Mounting Torque
12 to 14 in.lb
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
Yes
Specifications Series
610
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
7.5 kVDC at 70,000 ft. (simulated) at ambient temperature
Specifications Voltage Rating
5 kVDC
