610 SL Series Non-Sealed Front Panel Mount Receptacle
610 SL Series Non-Sealed Front Panel Mount Receptacle
SKU:HIG-44e03a
Discover the durable 610 SL Series Receptacle for high voltage applications. Ideal for aircraft use with 10 kVDC rating. Ensure safety and reliability in demanding environments.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
610 SL Series Non-Sealed Front Panel Mount Receptacle
$29.99
Quantity: 1
Claim Your Seller Account
610 SL Series Non-Sealed Front Panel Mount Receptacle
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 610 SL Series Receptacle, ideal for high voltage applications, features a larger coupling nut and unique threads for polarization to prevent cross mating. With a voltage rating of 10 kVDC, this connector is designed for aircraft and high mating operation environments. Its stainless steel coupling nut and BeCu contact material ensure durability and reliable connectivity. Meeting stringent MIL-spec standards, it offers superior performance and safety in demanding conditions.
Product Specifications
Body Properties Coupling Nut Finish
Passivated
Body Properties Coupling Nut Material
Stainless Steel
Contact Properties Contact Diameter
0.031 in | 0.79 mm
Contact Properties Contact Finish
Gold
Contact Properties Contact Material
BeCu
Specifications Altitudereduced Pressure Rating
Sea Level
Specifications Assembly Type
Receptacle Bag Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
1 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Lock Wire Holes In Coupling Nut
No
Specifications Mating Compatibility
Mates all Series 610 SL plug assemblies
Specifications Mating Torque
3 to 4 in-lbs
Specifications Mounting
Requires .197" (5.0 mm) dia. hole
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Front Mount
Specifications Panel Mounting Torque
12 to 14 in.lb
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
Yes
Specifications Series
610 SL
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
15 kVDC at Sea Level
Specifications Voltage Rating
10 kVDC
