6A Electro-Pneumatic Positioner - Single-Acting 4-20mA
6A Electro-Pneumatic Positioner - Single-Acting 4-20mA
SKU:ACT-7439c4
High-precision Series 6A Electro-Pneumatic Positioner for pneumatic applications, single-acting 4-20mA.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
6A Electro-Pneumatic Positioner - Single-Acting 4-20mA
$349.99
Quantity: 1
Claim Your Seller Account
6A Electro-Pneumatic Positioner - Single-Acting 4-20mA
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series 6A Electro-Pneumatic Positioner is a high-precision single-acting device designed for efficient control in pneumatic applications. With a supply pressure range of 20 to 102 psi and an analog input signal of 4 to 20 mA, this positioner offers exceptional resolution (<0.05%) and repeatability (0.32%). It features a rugged housing with NEMA 4,4x and IP66 protection, making it suitable for various industrial environments. Approved by FM, CSA, CE, and ATEX, this positioner ensures reliable performance, meeting demanding industry standards for quality and safety.
Product Specifications
Specifications Air Consumption
<0.00035 scfm
Specifications Analog Input Signal Dc
4 to 20 mA
Specifications Available Approvals
FM, CSA, CE, ATEX
Specifications Bus Input Signal
HART, Foundation Fieldbus, Profibus PA Connections
Specifications Control Element Type
Piezoelectric
Specifications Emc Requirements
EN 61326/A1 Appendix A.1 | NAMUR NE21 August 98
Specifications Housing Fasteners Material
Stainless Steel
Specifications Housing Material
Fiberglass Reinforced Polymer with Metalized Coated interior for EMC protection
Specifications Hysteresis
<0.2 %
Specifications Input Signal 2 Conduit Entries
1/2" NPT (M20x1.5)
Specifications Positioner Mounting
VDI/VDE 3845 (NAMUR)
Specifications Position Indicator Material
ABS polymer
Specifications Protection Class
NEMA 4,4x and IP66
Specifications Repeatability
0.32 %
Specifications Resolution
<0.05 %
Specifications Supply Input Signal
1/4" NPT (G 1/4")
Specifications Supply Pressure
20 to 102 psi | 1.4 to 7 bar
Specifications Temperature Range
-22 to +176 ºF | -30 to +80 ºC
Specifications Weight
2.0 lbs | 0.9 kg
