6mm Silicon Nitride Gas Pressure Sintered Sheet
6mm Silicon Nitride Gas Pressure Sintered Sheet
SKU:SIL-e00a87
High-quality 6mm Silicon Nitride Gas Sintered Sheet with exceptional mechanical and thermal properties for demanding industrial applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
6mm Silicon Nitride Gas Pressure Sintered Sheet
$129.99
Quantity: 1
Claim Your Seller Account
6mm Silicon Nitride Gas Pressure Sintered Sheet
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 6mm Thickness Silicon Nitride Gas Pressure Sintered Sheet is a high-quality ceramic material designed for industrial applications. Manufactured by Goodfellow Corp., this sheet boasts precise dimensions of 47 x 47 mm with a thickness of 6mm, meeting stringent tolerances. With exceptional mechanical properties including a fracture toughness of 7 Mpam0.5 and Vickers hardness of 1450 Kgf mm-2, this sheet offers excellent thermal conductivity at 22.00 Wm-1K-1. Its low apparent porosity of 0.00% and density of 3.240 g·cm-3 make it ideal for environments requiring resistance to high temperatures and chemicals, making it a reliable choice for demanding applications.
Product Specifications
Mechanical Properties Fracture Toughness
7 Mpam0.5
Mechanical Properties Hardness Vickers
1450 Kgf mm-2
Physical Properties Apparent Porosity
0.00 %
Physical Properties Density
3.240 g·cm-3
Specifications Form
Sheet
Specifications Size
47 x 47 mm
Specifications Thickness
6 mm
Thermal Properties Coefficient Of Thermal Expansion
3.600 x10-6 K-1
Thermal Properties Coefficient Of Thermal Expansion At Rt 1000
3.600 x10-6 K-1
Thermal Properties Thermal Conductivity
22.00 W m-1K-1 | 25.00 W m-1K-1
Tolerances Thickness Tolerance
10 %
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+2 % | -1 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
