7-Pole Light Gray Female Electrical Connector with Outdoor Rating

Name: 7-Pole Light Gray Female Electrical Connector with Outdoor Rating
Brand: Wieland Electric Inc.
SKU: CIR-bb76aa
Price: 27.99 USD
Availability: OutOfStock

SKU:CIR-bb76aa

High-quality 7-Pole Light Gray Female Electrical Connector for outdoor use, IP69 rated, 20A current capacity, secure screw connection.

$27.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 7-Pole Light Gray Female Connector is a high-quality pluggable electrical connector suitable for outdoor applications. Manufactured by Wieland, this connector features a straight angle plug with screw connection, ensuring secure and reliable electrical connections. With 7 poles and a 20 A current capacity according to IEC standards, it offers robust performance. The connector is IP69 rated for dust and water resistance, providing durability in harsh environments. Optional water seals on individual contacts enhance protection when unmated. From 250V to 600V rated voltages, this connector meets the needs of various industrial and institutional settings.

Product Specifications

Note Note

Optional water seals on individual contacts for added protection when unmated. Contact us for details.Technical details are subject to change

Specifications Angle Of Plug

Straight

Specifications Color Of Codingcontact Carrier

Light Gray

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Female

Technical Data Current According To Canadian Ul Recognized Unite

3 x 16 A + 4 x 2 A (Canada) (Contact us for Additional Combinations) | 3 x 20 A + 4 x 5 A (USA) (Contact us for Additional Combinations)

Technical Data Current According To International Electrotechnic

3 x 20 A + 4 x 5 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X/6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

10 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

6 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Wire Size According To Canadian Ul Listed United

20 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.2 to 1.5 mmÂ²
