70mm Diameter Power Disk Ceramic Capacitors - SPHT Series

Name: 70mm Diameter Power Disk Ceramic Capacitors - SPHT Series
Brand: High Energy Corp.
SKU: CER-207fd0
Price: 79.99 USD
Availability: OutOfStock

SKU:CER-207fd0

High-performance 70mm ceramic capacitors with up to 13kVDC & 20kV·A rating. Durable & reliable choice for industrial applications.

$79.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The SPHT 70 mm Diameter Power Disk Ceramic Capacitors are designed for high-performance applications, offering a working voltage of up to 13 kVDC and a power rating of up to 20 kV·A. With a capacitance range of 50 to 7000 pF and a choice of four Class I TC's, these capacitors provide reliable and efficient operation. The ceramic construction ensures durability and stability in demanding environments. Ideal for industrial and institutional use, these capacitors meet stringent quality standards and deliver excellent performance.

Product Specifications

Specifications Cap

160 pF

Specifications Diameter

70 mm

Specifications Dielectric Tc

NP0

Specifications Fh

12.7 MHz

Specifications Fl

0.235 MHz

Specifications Imax Rms

16 A

Specifications Smax

20 kV·A

Specifications Thread

Specifications Vmax Dc

13 kV

70mm Diameter Power Disk Ceramic Capacitors - SPHT Series
