8-Inch Spinmeister Extreme Duty Inlet Air Filter with Polyester Element
8-Inch Spinmeister Extreme Duty Inlet Air Filter with Polyester Element
SKU:SPI-f3f339
Experience unparalleled filtration with the 8-Inch Spinmeister Inlet Air Filter, designed for high dust environments. Maximize equipment lifespan!
Regular price
$499.99
Regular price
Sale price
$499.99
Unit price
per
Initiate Order
8-Inch Spinmeister Extreme Duty Inlet Air Filter with Polyester Element
$499.99
Quantity: 1
Claim Your Seller Account
8-Inch Spinmeister Extreme Duty Inlet Air Filter with Polyester Element
$499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 8-Inch Spinmeister Extreme Duty Inlet Air Filter with Polyester Element offers superior filtration in high dust environments, significantly extending filter element lifespan. With 85% efficiency at 15 microns and a 99%+ efficient pleated element, it ensures clean airflow in applications like blowers, cement engines, fans, foundries, grain elevators, and more. Constructed with durable materials, this configurable product can be tailored to specific needs, maintaining optimal performance and enhancing equipment longevity. Ideal for industrial settings requiring precision filtration and reliability.
Product Specifications
Dimensions Dimension A
31-1/2 in
Dimensions Dimension B
6 in
Dimensions Dimension C
22-1/2 in
Dimensions Dimension Tolerance
1/4 in
Features And Specifications 0
Polyester: 99%+ removal efficiency standard to 5 micronPaper: 99%+ removal efficiency standard to 2 micronFilter housing has heavy gauge carbon steel base with low pressure drop bracket and outlet pipe designDurable carbon steel housing constructionAll small compact filters are a seamless drawn housingTemp (continuous): min -15 ºF (-26 ºC ) max 220 ºF (104 ºC )Filter change out differential: 10"-15" H20 over initial delta P
Option 0
Multiple Configurations AvailableSpinMeisters available in Polished AluminumVacuum Systems configurationsSelected Housings available in SSVarious Media for Element1/8" taps for pressure drop indicators on selected modelsMultiple connection types
Specifications Applications And Equipment
Blowers | Cement Industry | Engines | Fans | Foundries | Grain Elevators | Plastics Industry | Pneumatic Conveying Systems | Screw Compressors | Wood Chip, Paper and Pulp Industries
Specifications Approximate Weight
103 lb
Specifications Connection Style
Flange (FLG)
Specifications Element Material
Polyester
Specifications Note
Model offerings and design parameters may change without notice
Specifications Outlet Size
8 in
Specifications Rated Flow
1800 scfm
Specifications Type
D
