9.5mm Aluminum Alloy Rod
9.5mm Aluminum Alloy Rod
SKU:ALU-69b658
High-quality 9.5mm Aluminum Alloy Rod with exceptional mechanical & electrical properties. Compliant with industry standards.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
9.5mm Aluminum Alloy Rod
$39.99
Quantity: 1
Claim Your Seller Account
9.5mm Aluminum Alloy Rod
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 9.5mm Aluminum Alloy Rod is a high-quality extruded rod crafted from Al97.5/Si 1.0/Mg 0.8/Mn 0.7 alloy, known for its exceptional mechanical and electrical properties. With a tensile strength of 340.00 MPa and shear strength of 210 MPa, this rod offers durability and reliability. Its thermal conductivity of 180.00 W m-1K-1 and electrical resistivity of 3.8 µΩ·cm make it ideal for a wide range of applications. Compliant with stringent industry standards, it meets the requirements of federal procurement standards and is TAA compliant for government procurement.
Product Specifications
Electrical Properties Electrical Resistivity
3.8 µΩ·cm
Material Material
Aluminum/Silicon/Magnesium/ManganeseAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
11.0 %
Mechanical Properties Hardness Vickers
100 Kgf mm-2
Mechanical Properties Modulus Of Elasticity
70.0 GPa
Mechanical Properties Shear Strength
210 MPa
Mechanical Properties Tensile Strength
340.00 MPa
Physical Properties Density
2.700 g·cm-3
Specifications Diameter
9.5 mm
Specifications Form
Rod
Specifications Length
100 to 1000 mm
Specifications Production Method
Extruded
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
24.000 x10-6 K-1
Thermal Properties Melting Point
555.00 ºC
Thermal Properties Specific Heat At 23 Degree Celsius C Temperat
894.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
180.00 W m-1K-1
Tolerances Tolerance For 100 Millimeter Mm Length Round
-1 % | +5 %
Tolerances Tolerance For 10 Millimeter Mm Diameter
5 %
Tolerances Tolerance For 10 Millimeter Mm Diameter
10 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
