9A Inductive AC T-Range 3-Pole Contactors with Pre-wired AC Operating Coil

9A Inductive AC T-Range 3-Pole Contactors with Pre-wired AC Operating Coil

DPC-da6bb9

9A Inductive AC T-Range 3-Pole Contactor with pre-wired AC coil, max 25A, high-quality design for electricity control applications.

$129.99
$129.99
Sale

Initiate Order

9A Inductive AC T-Range 3-Pole Contactors with Pre-wired AC Operating Coil

9A Inductive AC T-Range 3-Pole Contactors with Pre-wired AC Operating Coil

$129.99

Quantity: 1

Claim Your Seller Account

9A Inductive AC T-Range 3-Pole Contactors with Pre-wired AC Operating Coil

9A Inductive AC T-Range 3-Pole Contactors with Pre-wired AC Operating Coil

$129.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 9 Ampere (A) Maximum Inductive Alternating Current (AC) T-Range 3 Pole Mechanically Interlock Contactor is a high-quality solution for electricity control applications. With a max resistive AC of 25A, power ratings up to 7.5 hp, and auxiliary contacts for versatile functionality, this contactor meets stringent standards like BSEN60947, IEC60947, and CSA/UL approvals. Its compact design and wide operational temperature range from -40 to +70 ºC make it ideal for diverse settings. Accessories like power connectors and coil suppressors enhance its performance and reliability, ensuring seamless operations in demanding environments.

Product Specifications

Control Circuit Characteristics Average Consumption At 20 Degree
0.3 V·A
Control Circuit Characteristics Average Operating Time At Rated
4 to 12 ms
Control Circuit Characteristics Mechanical Life Rated Control Ci
15 cycles
Control Circuit Characteristics Operational Control Voltage For
0.8 to 1.1 Uc
Control Circuit Characteristics Rated Control Circuit Voltage Uc
12 to 660 V
Control Circuit Characteristics Rated Operational Voltage
0 to 660 V
Dimensions Depth D
80 mm
Dimensions Dimension C
80 mm
Dimensions Dimension D Lacdk1
133 mm
Dimensions Dimension D Ta1
113 mm
Dimensions Dimension D Ta2ta3
120 mm
Dimensions Dimension G
35 mm
Dimensions Height H
74 mm
Dimensions Minimum Electrical Clearance D
10 mm
Dimensions Width W
45 mm
Pole Characteristics Maximum Power Rating At Three Phase 200 Vol
2 hp
Pole Characteristics Maximum Power Rating At Three Phase 230 Vol
2 hp
Pole Characteristics Maximum Power Rating At Three Phase 480 Vol
5 hp
Pole Characteristics Maximum Power Rating At Three Phase 600 Vol
7.5 hp
Pole Characteristics Number Of Power Poles
3
Pole Characteristics Power Dissipation Per Pole For Ac 3 The Abo
0.2 W
Pole Characteristics Rated Breaking Capacity 220 To 440 Volt V
250 A
Pole Characteristics Rated Breaking Capacity 650 To 690 Volt V V
85 A
Pole Characteristics Rated Breaking Capacity At 500 Voltage V
175 A
Pole Characteristics Rated Insulation Voltage
1000 V
Pole Characteristics Rated Making Capacity Conforming To Interna
250 A
