A2 Stainless Steel Flat Head 6Lobe Torx® Drive Self-Tapping Sheet Metal Screw

Name: A2 Stainless Steel Flat Head 6Lobe Torx® Drive Self-Tapping Sheet Metal Screw
Brand: Aspen Fasteners
SKU: SCR-ca5959
Price: 49.99 USD
Availability: OutOfStock

SKU:SCR-ca5959

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Sheet Metal Screws, or Self-Tapping Screws, are thread cutting fasteners designed to be driven into untapped holes. They generally require a pre-drilled pilot hole (drill size dependent on the screw diameter and material thickness). They are available with a variety of points and thread styles in order to accommodate different material thickness.

Product Specifications

Additional Information

ISO 14586 formerly referred to the DIN 7982 specification.Also known as self-tapping screws, these are mostly used in thin gauge sheet metal applications.A 6-lobe recess is also known as a hexalobular internal drive.Flat countersunk head screws sit flush with the surface of the material they are inserted into.A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.Stainless steel significantly improves resistance to tarnishing or corrosion.

Specifications Coating

Uncoated

Specifications Drive Detail

Torx® Generic Alternative

Specifications Drive Style

6 Lobe Drive

Specifications Head Detail

80 Degree Countersink

Specifications Head Style

Flat Countersunk Head

Specifications Industry Standards And Specifications

International Organization for Standardization (ISO 14586)

Specifications Material

Stainless Steel

Specifications Material Grade

A2 Stainless Steel

Specifications System Of Measurement

Metric

Specifications Thread Direction

Right-Hand Thread

Specifications Thread Length

Full Thread
