A2 Stainless Steel Pan Phillips® Drive Full Thread Metric Machine Screw

Name: A2 Stainless Steel Pan Phillips® Drive Full Thread Metric Machine Screw
Brand: Aspen Fasteners
SKU: SCR-da225f
Price: 49.99 USD
Availability: OutOfStock

SKU:SCR-da225f

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

A fully threaded screw with unified machine thread and a blunt point. Usually used with a mating nut or driven into a pre-tapped hole. A large variety of head styles paired with numerous drives types allow for virtually unlimited uses.

Product Specifications

Additional Information

Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.Pan head screws are also known as raised cheese head screws.A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.Stainless steel significantly improves resistance to tarnishing or corrosion.

Specifications Coating

Uncoated

Specifications Drive Detail

Phillips® Type H

Specifications Drive Style

Cruciform Recess Drive

Specifications Head Style

Pan Head

Specifications Industry Standards And Specifications

German Institute for Standardization (DIN 7985A) | International Organization for Standardization (ISO 7045)

Specifications Material

Stainless Steel

Specifications Material Grade

A2 Stainless Steel

Specifications System Of Measurement

Metric

Specifications Thread Direction

Right-Hand Thread

Specifications Thread Length

Full Thread

A2 Stainless Steel Pan Phillips® Drive Full Thread Metric Machine Screw
